Features:
1. Rational heavy duty framework makes the machine run quite stably and durably.
2. Paper sheets feeding manually.
3. Regulating plate can be adjusted easily to regulate manual paper feeding.
4. Two heating rollers equipped are for one-side and double-side lamination purpose.
5. Heating roller is equipped with built-in electrical tube heater which makes temperature rise instantly. The laminating temperature is adjustable against different application.
6. Mechanical pressuring system provides pressure for lamination. And the pressure is adjusted by manual wheel.
7. Film trimmer cuts film width to make it meet paper size. The cut film will be winded by a film winder.
8. Laminated paper is rolled up automatically by the winding spindle. Winding speed is adjustable upon requests. Winded paper will be cut by manual work.
Parameters:
|
Model No.
|
KDFM-720
|
KDFM-900
|
KDFM-1000
|
KDFM-1200
|
|
Max Laminating Width
|
600mm
|
780mm
|
880mm
|
1020mm
|
|
Max Laminating Speed
|
20m/min
|
20m/min
|
20 m/min
|
20 m/min
|
|
Laminating Temperature
|
60-130℃
|
60-130℃
|
60-130℃
|
60-130℃
|
|
Gross Power
|
3.85kw
|
4.55kw
|
4.75kw
|
5.75kw
|
|
Total Weight
|
260kg
|
380kg
|
480kg
|
600kg
|
|
Overall Dimension
|
1150*1100*1400mm
|
1450*1100*1400mm
|
1550*1100*1450mm
|
1750*1250*1450mm
|
