Products > Laminating Machines and Embossing Machine > Embossing Machine > RYW920/1300 Automatic Embossing Machine for Paper Rolls
Product name : RYW920/1300 Automatic Embossing Machine for Paper Rolls
Item : 2013522135840
 Enlarge Image                   Back
             [Next Product]→


Details:
 The machine is applied to embossing some special paper rolls like plated paper, compound paper and artistic papers weighted from 30gsm to 400gs. It has automatic lift device equipped offering easy operation work. The veins and patterns of embossing rollers can be customized upon the requests.



Parameters:

Model

RYW-920

RYW-1150

RYW-1300

Paper Thickness

30-400g

30-400g

30-400g

Embossing Width

920mm

1150mm

1300mm

Speed

0-60m/min

0-60m/min

0-60m/min

Working Pressure

2-10Mpa

2-10Mpa

2-10Mpa

Power

20kw

22kw

24kw

Weight

4500kg

5500kg

6500kg

Dimensions

4800*2100*1450mm

4800*2230*1450mm

4800*2520*1450mm
