Suitable for printing variety of roll fabric materials like nylon ribbon, cotton ribbon, elastic ribbon, labels, strapping belts and satins etc
Features:
1. High printing registration and even ink distribution roller by roller
2. Automatic lubricating system ensuring a long well service life.
3. The main electric motor takes the advantage of frequency converter offering stable print speed and less power consumption.
4. The machine will automatically stop when the material runs out detected by photo sensor.
5. Printing length can be counted in automatically.
Parameters:
|
Model
|
UGS1002
|
UGS1004
|
UGS1006
|
UGS1007
|
|
Printing color
|
2/0, 1/1
|
4/0, 3/1
|
6/0, 5/1, 4/2
|
7/0, 6/1, 5/2
|
|
Roll Material Width
|
100mm
|
100mm
|
100mm
|
100mm
|
|
Print Area
|
95*398/mm
|
95*398/mm
|
95*398/mm
|
95*398/mm
|
|
Printing speed
|
0-60m/min
|
0-60m/min
|
0-60m/min
|
0-60m/min
|
|
Total power
|
0.75kw
|
0.81kw
|
1.5kw
|
1.5kw
|
|
Weight
|
550kg
|
850kg
|
960kg
|
1100kg
|
|
Dimension
|
1320*850*1480mm
|
1530*880*1560mm
|
1850*900*1680mm
|
1850*900*1750mm
|
|
